雙向差分壓力：

-5 .. 5 mbar --> -1000 .. 1000 mbar

差分壓力/相對壓力/表壓：

0 .. 5 mbar --> 0 .. 1000 mbar

絕對壓力：

0 .. 1000 mbar

      高精度的小型化的壓力傳感器模塊AMS 2712系列，工業標準二線制電流輸出4..20 mA，工作電壓范圍寬（8..36V），經過校準和溫度補償（-25 .. 85 °C），多種電氣輸出連接方式，具有短路保護和極性反向保護功能，適合工業上寬工作溫度范圍的精確壓力測量的應用。

主要參數

壓力范圍*	雙向差分壓力:	-5 .. 5 mbar --> -1000 .. 1000 mbar
	差分壓力/相對壓力/表壓:	0 .. 5 mbar --> 0 .. 1000 mbar
	絕對壓力:	0 .. 1000 mbar
	大氣壓力:	700 .. 1200 mbar
總誤差 (TEB)  (T = -25 °C .. 85 °C)	2.5 %FSO (max.)	微壓范圍 (≤ 10 mbar)
	2.0 %FSO (max.)	低壓范圍 (≤ 100 mbar)
	1.0 %FSO (max.)	標準壓力范圍 (> 100 mbar)
輸出電流	4 .. 20 mA
工作電壓	8 .. 36 V (典型 24 V)

Overview
AMS 2712 is a series of universal, ready-to-mount OEM pressure sensor modules with two-wire current-loop output (4 .. 20 mA) in various pressure ranges and configurations for the electrical connection. With AMS 2712’s large supply voltage range of 8 .. 36 V and its rugged, reverse polarity and short circuit protected current output the pressure sensor modules are especially suitable for industrial applications. Due to the extensive calibration and temperature compensation AMS 2712 allows precise pressure measurements in a wide temperature range of -25 .. 85 °C. The compact PCB pressure sensor modules from the AMS 2712 series can be easily integrated in other assemblies or used stand alone in a suitable package.


Available Pressure Ranges
? Differential (relative) pressure: 0 .. 5 mbar up to 0 .. 1 bar
? Bidirectional differential pressure: -5 .. +5 mbar up to -1 .. +1 bar
? Absolut pressure: 0 .. 1 bar
? Barometric pressure: 700 .. 1200 mbar
Custom specific pressure ranges or modifications are available on request.


Typical Applications
? Industrial process control
? Medical instrumentation
? HVAC (Heating, Ventilation, Air Conditioning)
? Vacuum monitoring
? Gas flow measurement
? Test benches
